Technical Specification Functional Characteristics
Model |
| |
Range of the Door | Single-leaf | Double-leaf |
Door Leaf max Weight | 180kg | 150kg x 2 |
Door Width | 500-2800mm | |
Motor | DC24V/65W Brushless Motor | |
Power Supply | AC110-240V, 50-60 Hz | |
Opening Speed | 450-750mm/s (adjustable) | |
Closing Speed | 450-750mm/s (adjustable) | |
Creep Speed | 30-100mm/s (adjustable) | |
Hold-open Time | 0-20s (adjustable) | |
Hold-Close Force | 70N<f<200N | |
Manual Pushing Force | <120N | |
Power Consumption | <150W | |
Ambient Temperature | -20+50 ℃ | |
